The Thuraya Neo M IP Terminal redefines battlefield connectivity with military-grade satellite communications engineered for speed, reliability, and security. Built rugged and compact, this mission-ready device keeps troops connected across the harshest terrains and most challenging conditions. From quick setup to instant signal acquisition, the Neo M delivers the portable communications solution modern operations demand. Experience uncompromising performance wherever your mission takes you.
High-Throughput Satellite Connectivity
The Thuraya Neo M IP Terminal, powered by the trusted Cobham hardware platform, delivers next-generation satellite communication with high throughput for mission-critical operations. Built for government agencies, military ensures seamless voice, video, and data connectivity even in the most challenging environments.
With support for VoIP, video conferencing, real-time monitoring, and advanced applications, the Neo C IP Terminal empowers organizations to stay connected, coordinate effectively, and maintain operational continuity in remote or disaster-affected regions. Rugged, reliable, and easy to deploy, it is the ultimate solution for professional satellite broadband over the Thuraya network.
Specifications
Data Capabilities
> 5° elevation: Up to 1024 kbps (Rx / Tx)
Voice: Standard VoIP
Embedded SIP Server
PPT Push-To-Talk
Frequency Range:
Tx (MHz)
Rx (MHz)
1626.5 - 1660.5 and 1668 - 1675
1518.0 - 1559.0
GNSS: GPS, Galileo, Beidou, Glonass
Languages:
Dimensions (H/W/D):
EN, AR, FR, PR, ES, RU, JP, CN
225 / 225 / 61.5 mm
Weight (incl. battery): 2.2 KG
Approval: CE, RED, RoHS, WEEE,
FCC, UL, RCM
Thuraya Type Approval
Power
DC input range: 12 - 24 VDC (max. 10.8 - 33.6 VDC)
PoE input: PoE (802.3bt Type 3 Class 6 via RJ45)
PoE output: PoE (802.3at Type 1 Class 2 via RJ45)
Power consumption:
Standby / Transmit:
During charging:
4.5W / 22W (typical)
75W (max.)
AC/DC power supply:
Input:
Output:
100-240 VAC, 47-63Hz, 64W
19 VDC
Built-in Battery:
Nom. voltage / capacity: 10.8 V / 6.9 Ah
Lithium ion (rechargeable)
Stand-by time: Up to 38 hours
Receive: Up to 4 hours @ 1024 Kbps
Transmit: Up to 3 hours @ 1024 Kbps
Recharge time: < 3 hours (0-100%)
Charge temperature: 0ºC to 45ºC
Environmental conditions
Temperature
Operational:
Storage:
-25°C to +55°C (ambient)
-40°C to +85°C
Water and dust: IP68
MIL-STD-810G: Method 503.6 (Temperature shock)
Method 505.6 (Solar Radiation)
Method 506.6 (Rain)
Method 507.6 (Humidity)
Method 509.6 (Salt Fog)
Method 510.6 (Sand and Dust)
Method 512.6 (Immersion)
Method 516.7 (Drop)
Method 524.1 (Freeze/Thaw)
EMI/EMC: MIL-STD-461H
Interfaces
WLAN Access Point: 802.11 b/g/n/ac
Ethernet Ports: 1 x RJ45 (PoE input for ext. power)
1 x RJ45 (PoE output IP Handset)
1 x RJ45
User interface:
2 x LED (Status and WLAN), Power Button,
Reset Button, Web Interface
USB Port: 1 x USB-C
Other features
Space42 Connect App: (Available for Android / IOS):
Control your IP NEO with your Smartphone
Set-up and Router Functionality:
Webserver, NAT Router, Admin control
(password protected), DHCP, Network Management,
Remote Management, PPPoE
Package
• IP NEO M Terminal with embedded Lithium-Ion Battery
• Quick Start Guide
• Power Cable, 3m open-ended
• Ethernet Cable
• 408052A-24/12 :009V DC cable, 3m open-ended
• 403650B-923: vPole Mount
• 408012A-42000: Space42 IP Handset
• 408016A-42000: Space42 Battery Pack
• 408016A-010: Space42 42 Battery Pack Extension
Cable, 4m
• 408052A-42000: Space42 Mobile Gateway M NEO
• 408020A-941: IP NEO PoE Cable with RJ-45 screw
connectors, 4m
• 408020A-943 IP NEO PoE Cable with RJ-45 screw
